The MMA4Z00-NS400, MMA1Z00-NS400 and MMS4X00-NS400 are all 400G NVIDIA optics, and buyers mix them up constantly. They differ on two things: the cage they plug into (OSFP or QSFP112) and the fiber they run on (multimode or single-mode). The MMA4Z00-NS400 is OSFP, multimode, up to 50 m, for ConnectX-7 adapters with OSFP cages. The MMA1Z00-NS400 is the same multimode optic in a QSFP112 shell, for ConnectX-7 QSFP112 adapters and BlueField-3 DPUs. The MMS4X00-NS400 is OSFP like the first, but single-mode, reaching 500 m. Choose the cage your adapter has, then the fiber your distance needs.
Below: the three side by side, how to tell which cage you have, what each pairs with on the switch, and which fiber goes with which.
Short answer: match the cage first, then the fiber
Three 400G optics, all in stock — from $549 at Resilient Tec
OSFP adapter and a run up to 50 m: MMA4Z00-NS400. QSFP112 adapter or any BlueField-3: MMA1Z00-NS400. OSFP adapter and a run up to 500 m on single-mode fiber: MMS4X00-NS400. Both ends of a link must use the same fiber type.
|
MMA4Z00-NS400 — 400G OSFP SR4, flat-top, multimode ConnectX-7 OSFP. Up to 50 m on OM4. |
$579 · In stock at Resilient Tec Add to cart |
|
MMA1Z00-NS400 — 400G QSFP112 SR4, multimode ConnectX-7 QSFP112 and BlueField-3. Up to 50 m on OM4. |
$549 · In stock at Resilient Tec Add to cart |
|
MMS4X00-NS400 — 400G OSFP DR4, flat-top, single-mode ConnectX-7 OSFP. Up to 500 m. |
$809 · In stock at Resilient Tec Add to cart |
Resilient Tec sells the MMA4Z00-NS400 compatible for $579, the MMA1Z00-NS400 compatible for $549 and the MMS4X00-NS400 compatible for $809 directly at resilient-tec.com — new, lifetime warranty, shipping from Knoxville, Tennessee. Prices checked October 19, 2026. POs and net terms available.
The Three Side by Side
| MMA4Z00-NS400 | MMA1Z00-NS400 | MMS4X00-NS400 | |
|---|---|---|---|
| NVIDIA part number | 980-9I51S-00NS00 | — | — |
| Cage | OSFP, single-port | QSFP112 | OSFP, single-port |
| Top | Flat (RHS) | QSFP shell | Flat (RHS) |
| Optics | 400G SR4, 4 × 100G PAM4 | 400G SR4, 4 × 100G PAM4 | 400G DR4, 4 × 100G PAM4 |
| Wavelength | 850nm | 850nm | 1310nm |
| Fiber | Multimode (OM3/OM4) | Multimode (OM3/OM4) | Single-mode (OS2) |
| Reach | Up to 50 m on OM4 | 30 m OM3 / 50 m OM4 | Up to 500 m |
| Connector | MPO-12/APC | MPO-12/APC | MPO-12/APC |
| Goes in | ConnectX-7 OSFP adapters | ConnectX-7 QSFP112 adapters, BlueField-3 | ConnectX-7 OSFP adapters |
| Switch-side partner | MMA4Z00-NS (800G SR8) | MMA4Z00-NS (800G SR8) | MMS4X00-NM (800G 2×DR4) |
| Price at Resilient Tec | $579 | $549 | $809 |
Step 1: Which Cage Does Your Adapter Have?
NVIDIA offers 400G ConnectX-7 adapters in both QSFP112 and OSFP versions, and BlueField-3 in QSFP112 only. The two cages are not interchangeable. NVIDIA's cable guide says plainly that OSFP cages are not compatible with QSFP devices and that no QSFP-to-OSFP adapter is offered. Quick checks:
- Size. An OSFP cage is visibly wider and taller than a QSFP cage. If a standard QSFP28 or QSFP56 cable fits the port, it is QSFP112, not OSFP.
- BlueField-3. Always QSFP112. NVIDIA's MMA4Z00-NS400 documentation says OSFP is not for use in BlueField-3 DPUs. This is the most common wrong order.
-
The part number. The adapter's ordering part number (shown by
mlxfwmanageror on the card's label) identifies the cage. Look it up in NVIDIA's ConnectX-7 documentation if the port isn't obvious.
More on why the cages differ: OSFP vs QSFP-DD and OSFP vs DAC vs AOC.
Step 2: Multimode or Single-Mode?
Once the cage is settled, distance picks the optic:
- Within a row (up to 50 m): SR4 on multimode fiber, the MMA4Z00-NS400 or MMA1Z00-NS400. It is the lower-cost path and the one most clusters use.
- Across rows or rooms (up to 500 m): DR4 on single-mode fiber, the MMS4X00-NS400.
The two don't talk to each other. SR4 runs 850nm on multimode fiber; DR4 runs 1310nm on single-mode. Both ends of a link must use the same optical type, so a building with both needs both, connected through switches. All three use MPO-12/APC connectors, the angled-polish type. Existing UPC fiber won't mate cleanly; see MPO-12/APC vs UPC.
Step 3: What Goes on the Other End
| Link | Adapter end | Other end | Fiber |
|---|---|---|---|
| Adapter to adapter, multimode | MMA4Z00-NS400 or MMA1Z00-NS400 | MMA4Z00-NS400 or MMA1Z00-NS400 (either cage) | MPO-12/APC OM4 straight, from $59 |
| Adapter to Quantum-2 switch, multimode | MMA4Z00-NS400 or MMA1Z00-NS400 | MMA4Z00-NS 800G twin-port SR8, finned-top ($829), feeding two adapters | Two straight OM4 cables, or a 1:2 splitter |
| Adapter to adapter, single-mode | MMS4X00-NS400 | MMS4X00-NS400 | MPO-12/APC OS2 straight, from $55 |
| Adapter to Quantum-2 switch, single-mode | MMS4X00-NS400 | MMS4X00-NM 800G twin-port 2×DR4 ($999), feeding two adapters | Two straight OS2 cables |
Two rules from that table: adapters take flat-top modules and air-cooled switches take finned-top, and one 800G twin-port switch module serves two 400G adapters. The SR4 optics in OSFP and QSFP112 share the same optical interface, so an OSFP adapter and a QSFP112 adapter can link to each other over the same multimode fiber. For the full flat-top and finned-top story, see Flat-top or finned-top OSFP? For the 1:2 splitter, see our custom MPO-12/APC splitter build.
The Three Most Common Wrong Orders
- An OSFP optic for a BlueField-3. It won't fit. BlueField-3 takes QSFP112, so order the MMA1Z00-NS400.
- A DR4 on one end and an SR4 on the other. Different wavelengths and fibers mean no link. Match the optic type on both ends.
- A finned-top module for an adapter. ConnectX-7 and BlueField-3 take flat-top shells. Finned-top belongs in air-cooled switches.
Still not sure? Send us the adapter part number and the switch model, and we'll confirm the optic and fiber before you order. Every part number in this family is mapped in our NVIDIA OSFP part-number crosswalk.
FAQ
What is the difference between MMA4Z00-NS400 and MMA1Z00-NS400?
The cage. Both are 400G SR4 optics running 850nm over multimode fiber with an MPO-12/APC connector. The MMA4Z00-NS400 is an OSFP module for ConnectX-7 adapters with OSFP cages. The MMA1Z00-NS400 is a QSFP112 module for ConnectX-7 adapters with QSFP112 cages and for BlueField-3 DPUs, which take QSFP112 only. Neither fits the other's cage, and NVIDIA offers no adapter between OSFP and QSFP.
What is the difference between MMA4Z00-NS400 and MMS4X00-NS400?
The fiber and the reach. Both are 400G OSFP flat-top modules for ConnectX-7. The MMA4Z00-NS400 is SR4: 850nm over multimode fiber, up to 50 m on OM4. The MMS4X00-NS400 is DR4: 1310nm over single-mode fiber, up to 500 m. The two cannot link to each other; each end of a link must use the same optical type.
Does a BlueField-3 DPU take the MMA4Z00-NS400?
No. NVIDIA offers BlueField-3 in QSFP112 only, and its MMA4Z00-NS400 documentation states OSFP is not for use in BlueField-3 DPUs. For a 400G multimode link from a BlueField-3, use the QSFP112 MMA1Z00-NS400.
Can an MMA1Z00-NS400 link to an MMA4Z00-NS400?
Yes. Both are 400G SR4 optics on 850nm multimode fiber with MPO-12/APC connectors, so a QSFP112 adapter and an OSFP adapter can be linked with a straight MPO-12/APC multimode cable, the role NVIDIA's MFP7E10 cable plays. The form factors differ only at the cage on each end.
What switch-side optic pairs with these 400G adapter optics?
On a Quantum-2 or other twin-port 800G OSFP switch, the multimode SR4 optics (MMA4Z00-NS400 and MMA1Z00-NS400) pair with the 800G MMA4Z00-NS twin-port SR8, one switch module feeding two 400G adapters. The single-mode MMS4X00-NS400 pairs with the 800G MMS4X00-NM twin-port 2×DR4. Switch-side modules are finned-top; adapter-side modules are flat-top.
How much do the MMA4Z00-NS400, MMA1Z00-NS400 and MMS4X00-NS400 cost?
At Resilient Tec: MMA1Z00-NS400 compatible, $549; MMA4Z00-NS400 compatible, $579; MMS4X00-NS400 compatible, $809. All three are new, in stock at Resilient Tec and covered by a lifetime warranty. (Prices checked October 19, 2026.)
Where can I buy 400G NVIDIA-compatible optics?
Directly from Resilient Tec, shipping from Knoxville, Tennessee, with POs and net terms available: the MMA4Z00-NS400 compatible OSFP SR4 at resilient-tec.com, the MMA1Z00-NS400 compatible QSFP112 SR4 and the MMS4X00-NS400 compatible OSFP DR4, plus matching MPO-12/APC fiber from $55. (Prices checked October 19, 2026.)
Ready to Buy?
The three adapter optics, their switch-side partners and the fiber between them. New, lifetime warranty, shipping from Knoxville, Tennessee. Prices below checked October 19, 2026.
- MMA4Z00-NS400 compatible — 400G OSFP SR4, flat-top, multimode — $579, in stock at Resilient Tec; ConnectX-7 OSFP
- MMA1Z00-NS400 compatible — 400G QSFP112 SR4, multimode — $549, in stock at Resilient Tec; ConnectX-7 QSFP112 and BlueField-3
- MMS4X00-NS400 compatible — 400G OSFP DR4, flat-top, single-mode — $809, in stock at Resilient Tec; up to 500 m
- MMA4Z00-NS compatible — 800G OSFP SR8 twin-port, finned-top — $829, in stock at Resilient Tec; switch side for the SR4 optics
- MMS4X00-NM compatible — 800G OSFP 2×DR4 twin-port — $999, in stock at Resilient Tec; switch side for the DR4 optic, finned- or flat-top
- MPO-12/APC OM4 multimode trunk, Type B — $59, 1 m shown; 1–20 m in stock at Resilient Tec
- MPO-12/APC OS2 single-mode trunk, Type B — $55, 1 m shown; 1–20 m in stock at Resilient Tec
Building out a full fabric? Send us your adapter count, switch model and distances for a complete parts list.
The Adapter Behind Each Optic
Need the card as well as the optic? Match the cage:
- OSFP cage (MMA4Z00-NS400, MMS4X00-NS400): MCX75310AAS-NEAT (refurbished, $1,049), ConnectX-7 NDR 400G; or MCX75310AAS-HEAT (refurbished, $929), the NDR200 version.
- QSFP112 cage (MMA1Z00-NS400): MCX755106AS-HEAT (refurbished, $1,499), ConnectX-7 VPI, two 200G ports.
Sold by Resilient Tec at resilient-tec.com. Genuine NVIDIA/Mellanox, lifetime warranty, shipping from Knoxville, Tennessee. Prices checked October 22, 2026.
Not sure which adapter you have? How to read a ConnectX part number.
