QSFP-100G-LR4-S, Cisco QSFP-100G-LR4-S – 100GBASE-LR4 QSFP28 Transceiver Module, Original, Refurbished
Warranty: Lifetime
Quick answer: The Cisco QSFP-100G-LR4-S is a 100GBASE-LR4 QSFP28 optic that runs 100 Gigabit Ethernet up to 10 km over single-mode fiber, using four wavelengths near 1310 nm on a duplex LC connector, with DOM. This listing is a genuine Cisco module. Resilient Tec sells it refurbished, with a lifetime warranty and free US shipping from Knoxville, TN.
Condition: Refurbished
Cisco QSFP-100G-LR4-S – 100GBASE-LR4 QSFP28 Transceiver Module
The Cisco QSFP-100G-LR4-S is a high-performance QSFP28 optical transceiver that delivers 100 Gigabit Ethernet connectivity over single-mode fiber. Designed for data centers, enterprise networks, and high-capacity backbone links, this module supports transmission distances up to 10 kilometers, providing reliable long-reach connections with low power consumption.
-
Form Factor: QSFP28
-
Data Rate: 100 Gbps
-
Wavelengths: 4 × 25 Gbps channels (1295 – 1309 nm)
-
Cable Type: Single-mode fiber (SMF)
-
Max Distance: Up to 10 km
-
Connector: Duplex LC
-
Operating Temperature: 0°C to 70°C
-
Hot-swappable: Yes
-
Digital Diagnostics (DOM): Supported
Engineered for Cisco platforms, the QSFP-100G-LR4-S ensures seamless compatibility and dependable high-speed optical performance.
Frequently Asked Questions
What fiber does it use?
Single-mode OS2 (9/125 µm) fiber with duplex LC connectors. It will not work over multimode fiber.
LR4 or SR4: which do I need?
LR4 is for single-mode runs up to 10 km, such as between buildings or rooms. SR4 is the lower-cost choice for multimode runs up to 100 m inside a data center, using MPO cabling.
Can I connect it to an LR4 optic from another brand?
Yes. 100GBASE-LR4 is an IEEE standard, so it links with any LR4 optic on the far end.
Is this an original Cisco part?
Yes, a Cisco-branded QSFP-100G-LR4-S, sold refurbished. It is also available new.
What warranty and shipping come with it?
Resilient Tec's lifetime warranty. US standard shipping is free with no minimum, and orders typically arrive in 3 to 5 days.
You Might Also Need
Cisco QSFP-100G-LR4-S, original new
OS2 LC to LC single-mode fiber cables
QSFP-100G-SR4-S Cisco Compatible, 100G QSFP28 SR4 Transceiver
All transceivers
